Wheeled Dry Powder Fire Extinguisher - BC Cartridge Pressure Type
Suitable Classess of Fire :
Certifications :
Capacity :
Features :
- Auto safety release mechanism
- Easy to move and operate
- Economical to maintain
- Welded with advanced MIG welding station & hydrostatic test as per standard
- UV resistant coating
- Controllable discharge mechanism with maximum retention of charge capacity
- Wide operating temperature range from -30° C to +55° C
Model Codes & Technical Specifications
| Capacity | Model | Agent | Gross Weight (kg) | Working Pressure (Bar) | CO₂ Gas Capacity | Fire Rating | Discharge Time (sec) | Bulk Range (mtr) |
|---|---|---|---|---|---|---|---|---|
| 25 kg | VFCPQ-25-S | SBC | 84 | 14 | 1 kg | 233B | 25 | 6 |
| VFCPQ-25-P | PBC | 233B | 25 | 6 | ||||
| 50 kg | VFCPQ-50-S | SBC | 120 | 14 | 2 kg | 233B | 40 | 8 |
| VFCPQ-50-P | PBC | 233B | 40 | 8 | ||||
| 75 kg | VFCPQ-75-S | SBC | 150 | 14 | 2kg | 233B | 50 | 10 |
| VFCPQ-75-P | PBC | 233B | 50 | 10 |
