Portable Dry Powder Fire Extinguisher - ABC Cartridge Pressure Type
Suitable Classess of Fire :
Certifications :
Capacity :
Features :
- CO₂ gas cartridge confirms to IS:4947
- Easy to operate and refill
- Economical to maintain
- Dependable drawn cylinders with hydrostatic test as per standard
- UV resistant coating
- Controllable discharge mechanism with maximum retention of charge capacity
- Wide operating temperature range from -30° C to +60° C
Model Codes & Technical Specifications
| Capacity | Model | Agent | Gross Weight (kg) | Cartridge | Working Pressure (Bar) | Fire Rating | Discharge Time (sec) | Bulk Range (mtr) |
|---|---|---|---|---|---|---|---|---|
| 4 kg | VFCPQ-04-50 | MAP 50% | 7.8 | 120 gm | 15 | 3A:89B | 18 | 3 |
| VFCPQ-04-90 | MAP 90% | 4A:144B | 18 | 3 | ||||
| 6 kg | VFCPQ-06-50 | MAP 50% | 11.1 | 120 gm | 15 | 4A:144B | 24 | 5 |
| VFCPQ-06-90 | MAP 90% | 6A:183B | 24 | 5 | ||||
| 9 kg | VFCPQ-09-50 | MAP 50% | 15.9 | 200 gm | 15 | 6A:183B | 31 | 6 |
| VFCPQ-09-90 | MAP 90% | 6A:233B | 31 | 6 |
