Portable Dry Powder Fire Extinguisher - BC Stored Pressure Type

Portable Dry Powder Fire Extinguisher - BC Stored Pressure Type
Portable Dry Powder Fire Extinguisher - BC Stored Pressure Type
Confirms to BIS
IS 15683:2018
Portable Dry Powder Fire Extinguisher - BC Stored Pressure Type
Sheet Thickness
1.8 mm
Portable Dry Powder Fire Extinguisher - BC Stored Pressure Type
Maximum Fire Rating
6A:233B
Portable Dry Powder Fire Extinguisher - BC Stored Pressure Type
Helium Leak Detection
On Demand
Portable Dry Powder Fire Extinguisher - BC Stored Pressure Type
CE Approved Valve
Brass
Portable Dry Powder Fire Extinguisher - BC Stored Pressure Type
EPDM Hose
Crack Resistant
Portable Dry Powder Fire Extinguisher - BC Stored Pressure Type
ISI Approved BC Powder
Min. 90%
Portable Dry Powder Fire Extinguisher - BC Stored Pressure Type
PP Internal & External Coating
Anti-Corrosive Treatment
Suitable Classess of Fire :
Portable Dry Powder Fire Extinguisher - BC Stored Pressure Type
Certifications :
Portable Dry Powder Fire Extinguisher - BC Stored Pressure Type
Capacity :
Portable Dry Powder Fire Extinguisher - BC Stored Pressure Type       Portable Dry Powder Fire Extinguisher - BC Stored Pressure Type       Portable Dry Powder Fire Extinguisher - BC Stored Pressure Type
Features :
  • Stored pressure type, hence always ready for action
  • Easy to operate & economical to maintain
  • Dependable drawn cylinders with hydrostatic test as per standard
  • UV resistant coating
  • Controllable discharge mechanism with maximum retention of charge capacity
  • Wide operating temperature range from -30° C to +60° C
Model Codes & Technical Specifications
Capacity Model Agent Gross Weight (kg) Working Pressure (Bar) Fire Rating Discharge Time (sec) Bulk Range (mtr)
4 kg VFBPQ-04-S SBC 7.1 15 144B 18 3
VFBPQ-04-P PBC 144B 18 3
6 kg VFBPQ-06-S SBC 9.6 15 183B 24 5
VFBPQ-06-P PBC 183B 24 5
9 kg VFBPQ-09-S SBC 13.9 15 233B 31 6
VFBPQ-09-P PBC 233B 31 6
