Wheeled Compressed Air Foam System - Low Pressure
V-Safe designed low pressure compressed air foam system (CAFs) is a pre-charged extinguishing equipment featured with specially designed nozzle that is capable of delivering water droplets in the range of microns. The reduced size of water droplets help in extinguishing fire in multiple ways: Cooling effect by evaporation; suffocation of fuel and oxygen thereby separating reaction partners; Deep penetration inside the flammable material. System is designed for less water consumption so as to reduce impact on environment.
Suitable Classess of Fire :
Certifications :
Capacity :
Features :
- Stainless steel body
- Compact and light weight design for easy handling & operation
- Highest fire rating in class
- Factory tested for high electrical conductivity test
- PESO Approved Breathing air bottle options available in MS and composite
- Higher efficiency than ordinary mist system
- Special nozzle: Facilitates foam release in both forms - Jet and Fog
Model Codes & Technical Specifications
Capacity | Model | Agent | Propellant | Gross Weight (kg) | Working Pressure | Hose Length | Fire Rating | Operating Time | Max. Discharge Range |
---|---|---|---|---|---|---|---|---|---|
50 ltr | VCAFSPQ-50 | AFFF | 6I/300 BAR Compressed Air | 110 | Upto 19 BAR | 10 m | 55A:IVB* | 220 Sec (Wet)/420 Sec(Dry) | 15 m (Wet)/8 m (Dry) |
