Portable Clean Agent Fire Extinguisher - Stored Pressure Type
Suitable Classess of Fire :
Certifications :
Capacity :
Features :
- Stored pressure type, hence always ready for action
- Easy to operate & recharge
- Dependable drawn cylinders with hydrostatic test as per standard
- UV resistant coating
- Ideal for protecting electronic equipment as the clean agent leaves no residue
- Wide operating temperature range from -30° C to +60° C
Model Codes & Technical Specifications
| Capacity | Model | MOC | Agent | Gross Weight (kg) | Working Pressure (Bar) | Fire Rating | Discharge Time (sec) | Bulk Range (mtr) |
|---|---|---|---|---|---|---|---|---|
| 2 kg | VFHPQ-02 | MS CRCA Grade 4 | HFC-236 | 4.1 | 10 | 1A:21B | 9 | 3 |
| 4 kg | VFHPQ-04 | HFC-236 | 7.1 | 10 | 2A:34B | 14 | 3.5 | |
| 6 kg | VFHPQ-06 | HFC-236 | 9.7 | 10 | 2A:55B | 22 | 4 | |
| 2 kg | VFHSSPQ-02 | SS 304 | HFC-236 | 3.6 | 10 | 1A:21B | 9 | 3 |
| 4 kg | VFHSSPQ-04 | HFC-236 | 6.5 | 10 | 2A:34B | 14 | 3.5 | |
| 6 kg | VFHSSPQ-06 | HFC-236 | 8.8 | 10 | 2A:55B | 22 | 4 |
