Wheeled Carbon Dioxide Fire Extinguisher - Cartridge Pressure Type

Wheeled Carbon Dioxide Fire Extinguisher - Cartridge Pressure Type
Wheeled Carbon Dioxide Fire Extinguisher - Cartridge Pressure Type
Confirms to BIS
IS 16018:2012
Wheeled Carbon Dioxide Fire Extinguisher - Cartridge Pressure Type
PESO/CCOE Approved
Confirms to IS:7285
Wheeled Carbon Dioxide Fire Extinguisher - Cartridge Pressure Type
ISI Approved Valve
Wheel Type
Wheeled Carbon Dioxide Fire Extinguisher - Cartridge Pressure Type
High Pressure Extinguisher
Wheeled Carbon Dioxide Fire Extinguisher - Cartridge Pressure Type
Maximum Fire Rating
89B
Wheeled Carbon Dioxide Fire Extinguisher - Cartridge Pressure Type
Braided Hose
Wheeled Carbon Dioxide Fire Extinguisher - Cartridge Pressure Type
Electrics Fire Friendly
Wheeled Carbon Dioxide Fire Extinguisher - Cartridge Pressure Type
Enamel Painted Body
Suitable Classess of Fire :
Wheeled Carbon Dioxide Fire Extinguisher - Cartridge Pressure Type
Certifications :
Wheeled Carbon Dioxide Fire Extinguisher - Cartridge Pressure Type
Capacity :
Wheeled Carbon Dioxide Fire Extinguisher - Cartridge Pressure Type       Wheeled Carbon Dioxide Fire Extinguisher - Cartridge Pressure Type       Wheeled Carbon Dioxide Fire Extinguisher - Cartridge Pressure Type
Features :
  • Stored pressure type, hence always ready for action
  • Easy to operate & economical to maintain
  • Electrical non conductive agent & leaves no residue
  • Frost free horn that cause no freeze burns
  • Controllable discharge mechanism with maximum retention of charge capacity
  • Wide operating temperature range from -30° C to +55° C
Model Codes & Technical Specifications
Capacity Model Agent Gross Weight (kg) Working Pressure (Bar) Fire Rating Discharge Time (sec) Bulk Range (mtr)
6.5 kg VFCPQ-6.5 CO₂ 24 60 55B 20 3
9 kg VFCPQ-9 CO₂ 35 60 55B 30 3
22.5 kg VFCPQ-22.5 CO₂ 85 60 89B 47 4
