Portable Foam Base Fire Extinguisher - Cartridge Pressure Type
Suitable Classess of Fire :
Certifications :
Capacity :
Features :
- CO₂ gas cartridge confirms to IS:4947
- Easy to operate and refill
- Economical to maintain
- Dependable drawn cylinders with hydrostatic test as per standard
- Air aspirated nozzle
- Controllable discharge mechanism with maximum retention of charge capacity
- Wide operating temperature range from +5° C to +60° C
Model Codes & Technical Specifications
| Capacity | Model | Agent | Gross Weight (kg) | Cartridge | Working Pressure (Bar) | Fire Rating | Discharge Time (sec) | Bulk Range (mtr) |
|---|---|---|---|---|---|---|---|---|
| 6 ltr | VFMCPQ-06-03 | AFFF 3% | 10.0 | 60gm | 15 | 2A:34B | 22 | 4 |
| VFMCPQ-06-06 | AFFF 6% | |||||||
| VFMCPQ-06-13 | AR AFFF 3/3% | |||||||
| VFMCPQ-06-16 | AR AFFF 3/6% | |||||||
| 9 ltr | VFMCPQ-09-03 | AFFF 3% | 15.6 | 60gm | 15 | 4A:233B | 38 | 6 |
| VFMCPQ-09-06 | AFFF 6% | |||||||
| VFMCPQ-09-13 | AR AFFF 3/3% | |||||||
| VFMCPQ-09-16 | AR AFFF 3/6% |
