Portable Class D Metal Fire Extinguisher - Stored Pressure Type

Portable Class D Metal Fire Extinguisher - Stored Pressure Type
Portable Class D Metal Fire Extinguisher - Stored Pressure Type
Works on Metal Fire
Portable Class D Metal Fire Extinguisher - Stored Pressure Type
Sheet Thickness
Up to 2.5 mm
Portable Class D Metal Fire Extinguisher - Stored Pressure Type
CE Approved Valve
Brass
Portable Class D Metal Fire Extinguisher - Stored Pressure Type
EPDM Hose
Crack Resistant
Portable Class D Metal Fire Extinguisher - Stored Pressure Type
Helium Leak Detection
On Demand
Portable Class D Metal Fire Extinguisher - Stored Pressure Type
PP Internal & External Coating
Anti-Corrosive Treatment

V-Safe brand Class D fire extinguishers are applicable on reactive metal fires with application area in power plants, battery manufacturing units, explosive industries, nuclear power plants, metallurgical plants, pharmaceuticals and chemical plants as well as units handling flammable metals in aggressive state.

Sodium chloride based agent is applicable on metal fire of Mg, Al powders & paste, Ti, Fe and their alloys with spills and in depth fire source.

Ternary Eutectic Chloride (TEC) based agent is applicable on fire lithium and its alloys mainly used in batteries and other such applications.

Suitable Classess of Fire :
Portable Class D Metal Fire Extinguisher - Stored Pressure Type
Certifications :
Portable Class D Metal Fire Extinguisher - Stored Pressure Type
Capacity :
Portable Class D Metal Fire Extinguisher - Stored Pressure Type       Portable Class D Metal Fire Extinguisher - Stored Pressure Type       Portable Class D Metal Fire Extinguisher - Stored Pressure Type
Features :
  • Easy to operate & maintain
  • Specially designed extension diffusers for soft flow to fight aggressive metal fires
  • Applicable on Li-ion battery fire
  • Stored Pressure type, hence always ready for action
Model Codes & Technical Specifications
Capacity Model Agent Propellant Gross Weight (kg) Working Pressure (Bar) Discharge Time (sec) Operating Temperature
4 kg VFMPQ-04 TEC / Sodium Chloride Stored pressure with N₂ 7.5 15 25 -30° C to +60° C
6 kg VFMPQ-06 9.5 15 30
9 kg VFMPQ-09 14.5 15 30
