Modular Clean Agent Fire Extinguisher - Stored Pressure Type
Suitable Classess of Fire :
Certifications :
Capacity :
Features :
- Always ready for action
- Provides security in case of emergencies and power failure
- Fire detection & suppression system in a single unit
- UV resistant coating
- Dependable drawn cylinders with hydrostatic test at 35 bar
- Wide operating temperature range from -30° C to +60° C
Model Codes & Technical Specifications
| Capacity | Model | Agent | Gross Weight (kg) | Working Pressure (Bar) | Discharge Time (sec) | Mounting Height Above Risk | Bulk Range (mtr) |
|---|---|---|---|---|---|---|---|
| 2 kg | VMCPQ-02-36 | HFC-236 | 3.5 | 15 | 4 to 5 | 1.5 mtr | 1 to 1.5 m² |
| VMCPQ-02-27 | HFC-227 | 4 to 5 | 1.5 mtr | 1 to 1.5 m² | |||
| 5 kg | VMCPQ-05-36 | HFC-236 | 7.6 | 15 | 6 to 8 | 2 mtr | 2 to 2.5 m² |
| VMCPQ-05-27 | HFC-227 | 6 to 8 | 2 mtr | 2 to 2.5 m² | |||
| 10 kg | VMCPQ-10-36 | HFC-236 | 14.1 | 15 | 10 to 15 | 2.25 mtr | 4 to 5 m² |
| VMCPQ-10-27 | HFC-227 | 10 to 15 | 2.25 mtr | 4 to 5 m² | |||
| 15 kg | VMCPQ-15-36 | HFC-236 | 21.4 | 15 | 15 to 20 | 2.5 mtr | 5 to 6 m² |
| VMCPQ-15-27 | HFC-227 | 15 to 20 | 2.5 mtr | 5 to 6 m² |
